Product Description
Heavy-duty truss belt conveyor designed for concrete batch plants, aggregate processing facilities, and industrial material handling applications. Engineered for long-span material transfer, the truss conveyor provides exceptional structural strength while minimizing support requirements and maintaining efficient material flow.
Constructed using L3 x 3 x 1/4 and L2 x 2 x 1/4 structural angle truss members, the conveyor is designed for long service life, dependable performance, and efficient operation in demanding industrial environments. Utilizing industry-standard CEMA conveyor components, the system offers excellent durability, serviceability, and replacement part availability.
Available Configuration Options
• Belt Widths: 18", 24", 30", and 36"
• Lengths: 20', 40', and Custom
• 20° Troughing Idlers Available
• 35° Troughing Idlers Available
• Walkway and Handrail Packages Available
• Multiple Drive Configurations Available
• Multiple Discharge Arrangements Available
• Custom Plant Integration Configurations Available
Specifications
Application: Aggregate and Bulk Material Transfer
Construction: L3 x 3 x 1/4 and L2 x 2 x 1/4 Structural Angle Truss Construction
Configuration: Truss Belt Conveyor
Troughing Idlers: Standard CEMA Rollers, 20° or 35° Troughing Configuration
Return Idlers: 4" Diameter Return Rollers
Drive Package: 10 HP Heavy-Duty Conveyor Motor (Voltage Specified by Customer)
Drive Assembly: Gearbox and Torque Arm Assembly Included
Pulley Package: Head and Tail Pulley Package with Take-Ups Included
Finish: Industrial Protective Coating
Installation Type: Field-Assembled Structural System
Compatible With
• Concrete Batch Plants
• Ready-Mix Concrete Operations
• Aggregate Storage Systems
• Sand and Gravel Processing Facilities
• Mining Operations
• Industrial Material Handling Systems
Features
• L3 x 3 x 1/4 and L2 x 2 x 1/4 structural angle truss construction
• Designed for long-span conveyor applications
• Standard CEMA conveyor roller components
• Available with 20° or 35° troughing idler configurations
• Standard 4" diameter return idlers
• Includes 10 HP heavy-duty conveyor motor
• Customer-specified motor voltage available
• Includes drive and gearbox assembly with torque arm
• Includes head and tail pulley package with take-ups
• High strength-to-weight structural design
• Reduced intermediate support requirements
• Optimized material flow characteristics
• Designed for continuous industrial operation
• Simplified field assembly and installation
• Engineered for outdoor industrial environments
• Long service life design
• Customizable to suit specific plant requirements
